deutz engine TCD 2.2 L3 New
Newly developed 3-cylinder in-line engine with cooled external exhaust gas recirculation with and without turbocharging and optionally with and without charge air cooling.
product details
Newly developed 3-cylinder in-line engine with cooled external exhaust gas recirculation, with and without turbocharging and optionally with and without charge air cooling.Robust motor for demanding industrial applications, based on the successful TCD 2.9 series.
The use of the DVERT® Oxidation Catalyst (DOC) enables maintenance-free operation under all possible uses and ambient conditions for Tier 4, or with DVERT® Particle Filters (DPF) for Stage V.
The powerful common rail injection system and highly efficient combustion ensure the best engine performance with the lowest fuel - and emission values.
Similar connection dimensions and main installation interfaces as TCD 2.9 and G 2.2 / G 2.9 LPG engines for easy installation in diesel and gas powered devices.
Oil change intervals of up to 1000 h, a maintenance-free valve train and optionally a maintenance-friendly multiple V-belt drive lead to low maintenance costs and high device availability.
Variants without EAT and for less regulated markets will expand the product range in the future.
The engines are equipped with a modular exhaust gas aftertreatment system (EAT), which can optionally be attached to the engine. This considerably simplifies device integration for the OEM and practically means a “drop-in” solution.
100% power take-off on the flywheel and front side and additional side power take-off with up to 120 Nm for the attachment of up to two hydraulic pumps.
The very compact motor design and a customer-oriented, modular system of optional add-on parts reduce installation costs and increase the number of applications.
Technical specifications | |
---|---|
emission standards | EU V, US T4f |
model series | TCD 2.2 / 2.9 |
number of cylinders | 3 |
drilling | 92 mm |
stroke | 110 mm |
displacement | 2.2 l |
Max. Rated speed | 2600 min -1 |
power | 55.4 kW |
at speed | 2600 min -1 |
Max. Torque | 280 Nm |
at speed | 1600 min -1 |
Lowest idle speed | 900 min -1 |
length | 576 mm |
width | 578 mm |
height | 754 mm |
Weight | 215 kg |
Q1. What is your terms of packing?
A: Generally,we pack our goods in neutral Carton with pallet or non-fumigation plywoodcase.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you photos of products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW,FOB,CFR,CIF,DDU
Q4. How about your delivery time?
A: Generally, it will take 1 to 2 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. How do you make our business long-term and good relationship?
A:1. We Keep Good Quality And Competitive Price To Ensure Our Customers Benefit ;
2. We Respect Every Customer As Our Friend And We Sincerely Do Business And Make Friends With Them, No Matter Where They Come From.
Q6.If I only had the engine NO., Can you find the matching parts quickly for me?
A: Yes, we are equipped with the latest version of Deutz Serpic 2021, you only need to provide the engine nameplate or serial number, we can quickly and accurately provide information on engine assembly and parts.
A: Please click to Finding your Deutz Engine Serial Number?
